STANDARD LAGUN TABLE SYSTEM (WITH HARDWARE)
- Unit Price
This sleek and modern design of the Lagun table system is perfect for your van. Eliminate your wobbly table and get peace of mind.
The Lagun table system has quick and easy locks on each junction which allows a solid hold it will always remain stable during the trip. It rotates right where you want it, or out of the way and locks in any position you choose. It can also be moved to additional mounting plate points in seconds.
You can use your old tabletop or Lonavity makes custom tabletops contact us for more details.
The Lagun is easy to install and in practically no time. The pieces all connect at the lower part of the table base for easy storage and a snap to set up or takedown. Stabilize your active lifestyle with a Lagun Table System!
DOWNLOAD THE STANDARD LAGUN TABLE SYSTEM USER GUIDE
Please note that the mounting plate must be installed on a solid vertical surface.
Lagun Table System Specification:— From the bottom of the leg to the top of the table, mounting plate is 231/2″.
— Swivels 360 degrees on two points.
— Total maximum weight is 50 lb (includes the tabletop and anything you put on the tabletop).
— Maximum tabletop size is 30″ × 40″.
— Does NOT include a tabletop, but in most cases, you can reuse your existing tabletop.
— All parts are also available separately to keep your Lagun working for years of use.
— Salt water can’t harm the Lagun.
Included in the kit:
— Standard Leg
— Table Mounting Plate
— Hardware Kit (1 Teak Board, 2 Wedges, 4 Stainless Steel Bolts, 4 Nuts, 4 Washers)
|Arm with ends caps||16″|
|Arm without ends caps||153/4″|
|Arm centre of bushing||123/4″|
|Standard Leg with the splined tap||213/4″|
|Standard Leg alum tube||1911/16″|
|Standard Leg Groove from the bottom of the leg||111/2″|
|Table Mounting Plate||77/8″ x 11 13/16″|
|Bracket||31/2″ × 7″|
|Teak Board||611/16″ x 9 3/8″ and 1/2″ thick|
|Stainless Steel Bolts, nuts, washers||8 mm × 2″|
