🔌 All-in-One Power Hub

The EcoFlow Power Hub integrates multiple electrical components into a single compact unit, simplifying installation and reducing wiring complexity.

⚡3600W AC Output

Delivers 3600W AC output capable of powering common appliances used in vans, RVs, and off-grid builds.

🔋Four Charging Methods

• Up to 4800W solar input (3 × 1600W ports)
• 1000W alternator charging while driving
• 3000W shore power input
• 1800W Smart Generator input

Solar panels are sold separately.

🧱Expandable Battery System

Stackable 2kWh and 5kWh LiFePO₄ batteries allow total system capacity up to 15kWh depending on configuration.

🔧48V Electrical Architecture

The 48V system reduces electrical current compared to traditional 12V systems, helping minimize heat generation and power loss.

📱Smart Monitoring & Control

Monitor and manage your system using the EcoFlow Power Kit Console or the EcoFlow mobile app for real-time system monitoring.

Power Hub

• Net Weight: 14 kg (31 lb)
• Dimensions: 480 × 140 × 300 mm (18.9 × 5.5 × 11.8 in)
• Wi-Fi: Supported (2.4G, <120 m)
• Bluetooth: Supported (<15 m)
• Mobile App: Supported
• AC Output: Pure Sine Wave, 3600W (7200W surge), 120V, 60Hz
• DC Output: 13.6V / 70A (1000W max), 26.4V / 60A (1600W max)
• AC Input: X-Stream fast charging, 3000W max, 30A max
• AC Input Voltage: 120V, 60Hz
• Operating Temperature: −25°C to 60°C (−13°F to 140°F)
• Storage Temperature: −25°C to 60°C (−13°F to 140°F)

LFP Batteries

• Battery Options: 2kWh or 5kWh LiFePO₄ batteries
• Protection Rating: IP54

Power Kit Console

• Touch Screen: 7-inch display (6 × 3.4 in)
• Power Supply Voltage: 12 VDC
• Operating Temperature: −4°F to 140°F

AC/DC Smart Distribution Panel

• AC Input: 30A max, 120V, 3600W
• DC Input: 70A max
• AC Output: 6 AC positions (20A max each)
• DC Output: 12 fused DC positions (6 controllable via console or app)
• Operating Temperature: −13°F to 140°F
• Dimensions: 8.3 × 13.9 × 3.9 in (H × W × D)
• Net Weight: 5.7 lb
• Protection Rating: IP21

Certifications

• UL
• FCC
• ICES
• CE
• UKCA
• E-Mark
• RCM
• TELEC
• KCC

Click the links below to access the installation guides:

👉 EcoFlow Power Hub User Manual


👉 EcoFlow Power Kit Console User Manual

👉 EcoFlow 2kWh & 5kWh LFP Battery User Manual

👉 EcoFlow Battery Power Distribution Terminal Manual

👉 EcoFlow Alternator Charger 800W
